All type of bearing koyo 5209 bearing nsk angular contact ball
bearing
Description:
| Model Number | 5300 bearings |
| Size | 10x35x19 mm |
| Weight: | 0.092kg |
| Structure | angular contact ball bearing |
| Material | Gcr15/AISI52100/100Cr6 |
| Clearance | C0,C2,C3,C4,C5 |
| Vibration | ZV1,ZV2 and ZV3 |
| Precision Rating | P0,P6,P5 |
| Greese | As you requirement, such as SRL and so on |
| Number of Row | Double Row |
| Guarantee | One year. |
Specification:
1. High precision bearings
2. ISO standard bearing
3. High quality and competitive price
4. Many famous brands can be available
5. Low noise and long life
Applications:
Single row angular contact ball bearings are usually used in
machine tool spindles, high-frequency motors, gas turbines,
centrifugal separators, the front hub of mini vehicles,
differential pinions, etc.
Double row angular contact ball bearings are extensively used in
oil pumps, roots blowers, air compressors, various transmissions,
printing machines and fuel injection pumps, and more.
Features:
1) Quality level: reach the same level as the Japanese and European
bearings
2) Less coefficient of friction
3) High limiting speed
4) Large size range
5) variations of structure
6) Typical applications: speed reducers, automotive applications,
construction equipment, pumps and printing presses
7) Main products: 3202 series, 3303 series, 5200 series,5300
series, 7000 series, 7200 series and 7300 series.
Series model:
| Bearing No. | Boundary Dimensions(mm) | Basic Load Ratings(N) | Limiting Speeds(RPM) | Mass(kg) |
| d | D | B | r min | Cr | C0r | Grease | Oil | approx |
| 5200 | 10 | 30 | 14.3 | 0.6 | 7 150 | 3 900 | 17 000 | 22 000 | 0.05 |
| 5201 | 12 | 32 | 15.9 | 0.6 | 10 500 | 5 800 | 15 000 | 20 000 | 0.06 |
| 5202 | 15 | 35 | 15.9 | 0.6 | 11 700 | 7 050 | 13 000 | 17 000 | 0.07 |
| 5302 | 42 | 19 | 1 | 17 600 | 10 200 | 11 000 | 15 000 | 0.11 |
| 5203 | 17 | 40 | 17.5 | 0.6 | 14 600 | 9 050 | 11 000 | 15 000 | 0.09 |
| 5303 | 47 | 22.2 | 1 | 21 000 | 12 600 | 10 000 | 13 000 | 0.14 |
| 5204 | 20 | 47 | 20.6 | 1 | 19 600 | 12 400 | 10 000 | 13 000 | 0.12 |
| 5304 | 52 | 22.2 | 1.1 | 24 600 | 15 000 | 9 000 | 12 000 | 0.23 |
| 5205 | 25 | 52 | 20.6 | 1 | 21 300 | 14 700 | 8 500 | 11 000 | 0.19 |
| 5305 | 62 | 25.4 | 1.1 | 32 500 | 20 700 | 7 500 | 10 000 | 0.34 |
| 5206 | 30 | 62 | 23.8 | 1 | 29 600 | 21 100 | 7 100 | 9 500 | 0.29 |
| 5306 | 72 | 30.2 | 1.1 | 40 500 | 28 100 | 6 300 | 8 500 | 0.51 |
| 5207 | 35 | 72 | 27 | 1.1 | 39 000 | 28 700 | 6 300 | 8 000 | 0.43 |
| 5307 | 80 | 34.9 | 1.5 | 51 000 | 36 000 | 5 600 | 7 500 | 0.79 |
| 5208 | 40 | 80 | 30.2 | 1.1 | 44 000 | 33 500 | 5 600 | 7 100 | 0.57 |
| 5308 | 90 | 36.5 | 1.5 | 56 500 | 41 000 | 5 300 | 6 700 | 1.05 |
| 5209 | 45 | 85 | 30.2 | 1.1 | 49 500 | 38 000 | 5 000 | 6 700 | 0.62 |
| 5309 | 100 | 39.7 | 1.5 | 68 500 | 51 000 | 4 500 | 6 000 | 1.4 |
Competitive Advantage:
1. Excellent and high-quality control
2. Fast delivery
3. Competitive price
4. Small order accepted
5. Customers' drawing or samples accepted
6. Less vibration and noise
7. Large Inventories
Packaging & Shipping;
Packaging Details
1, Industry packaging: Plastic tube + Carton + pallet
2, Commercial packaging: Single color box+Carton+pallet
3, According to the requirement of customers'
