26mm OD 10mm Skf Deep Groove Ball Bearing 6000-2Z Very Light 6000 Series

Ask Lasest Price
Brand Name :	YGB,SKF,NT, OEM
Model Number :	6000-2Z
Certification :	ISO9001:2008
Price :	negotiation
Payment Terms :	T/T , L/C
Supply Ability :	1,000,000pcs per month
Delivery Time :	within 5- 10 working days after received your payment

Add to Cart

Product Details
Company Profile

26mm OD 10mm Skf Deep Groove Ball Bearing 6000-2Z Very Light 6000 Series

26mm O.D, 10mm Deep Groove Ball Bearing 6000-2Z skf, Very Light 6000 Series

Description :

Model	6000 2Z
Bearing type	Deep groove ball bearings
IDODW (mm)	10 x 26 x 8mm
Weight(kg)	0.02
Basic dynamic load ratings/C	4.75 kN
Basic static load ratings/C0	1.96 kN
Fatigue load limit	0.038 kN
Reference speed	67000 rmp/min
Limiting speed	34000 rmp/min
Rows	Single
Seals of shields	Metal shields on both sides of bearing
MOQ	Negotiated
Lead time	Stock or 15-30days
Port	Shanghai
Payment terms	T/T, L/C

The Drawing:

Series Models:

Basic	Nominal Bearing Dimensions			Preferred Shoulder Diameters
Bearing	d	D	B,C	r (min)	da (min)	da (max)	Da (max)
No.	mm	mm	mm	mm	mm	mm	mm
604	4	12	4	0.2	5.4	6.6	10.6
605	5	14	5	0.2	6.6	7.4	12.4
606	6	17	6	0.3	8	8.6	15
607	7	19	6	0.3	9	10.4	17
608	8	22	7	0.3	10	12.2	10
609	9	24	7	0.3	11	13.1	12
6000	10	26	8	0.3	12	13.5	24.1
6001	12	28	8	0.3	14	16	26
6002	15	32	9	0.3	17	19	30
6003	17	35	10	0.3	19	21.5	33
6004	20	42	12	0.6	24	26	38
6005	25	47	12	0.6	29	30.5	43
6006	30	55	13	1	35	37	50
6007	35	62	14	1	40	42	57
6008	40	68	15	1	45	47.5	63
6009	45	75	16	1	50	53.5	70
6010	50	80	16	1	55	58.5	75
6011	55	90	18	1.1	61.5	64.2	83.5
6012	60	95	18	1.1	66.5	69.1	88.5
6013	65	100	18	1.1	71.5	74	93.5
6014	70	110	20	1.1	76.5	80.5	103.5
6015	75	115	20	1.1	81.5	85.6	108.5
6016	80	125	22	1.1	86.5	91.5	118.5
6017	85	130	22	1.1	91.5	97	123.5
6018	90	140	24	1.5	98	102	132
6019	95	145	24	1.5	103	109	137
6020	100	150	24	1.5	108	110	142
6021	105	160	26	2	114	119	151
6022	110	170	28	2	119	126	161
6024	120	180	28	2	129	136	171
6026	130	200	33	2	139	148	191

Common Options
Z	: One Shield
ZZ	: Two Shields
RZ	: One Non-Contact Seal
2RZ	: Two Non-Contact Seals
RS	: One Contact Seal
2RS	: Two Contact Seals
RS1	: One Tight sealing type
2RS1	: Two Tight sealing type
C0	: Normal Internal Clearance
C3	: Greater Than Normal
EMQ	: Electric Motor Quality

Different applications of different bearings:

Payment:

1: T/T: 30% as deposit and 70% balance after getting a copy of B/L.
2: L/C (cannot for branded bearings.)
3: Discuss together between buyer and supplier.
