FAG Grooved Race Single Direction Thrust Ball Bearing 51108 60mm
Open, 90° Contact Angle
Description :
| Model | 51108 |
| Bearing material | Steel |
| ID*OD*W (mm) | 40x60x13mm |
| Seals of shields | Open type |
| Weight(kg) | 0.12 |
| Basic dynamic load ratings/C | 25.5 kN |
| Basic static load ratings/C0 | 63 kN |
| Fatigue load limit | 2.32 |
| Reference speed | 5000 rmp/min |
| Limiting speed | 7000 rmp/min |
| Lead time | Stock or 15-30days |
| Port | Shanghai |
| Grease | Mobil polyrex EM, Kyodo Yushi SRL |
The drawing:
The features:
These bearings are essential for tall rotating applications (mostly
over 4 feet in height). Thrust bearings are ideal for applications
experiencing heavy axial loads, such as mill stands, screw-down
systems, and piercing mills.
Applications:
• Agricultural industry
• Food processing
• Machine tools
• Material Handling
• Printing
FAG Related thrust ball bearings:
| New | Old | Main Dimension | Load rating / KN | Maximum speed | Weight |
| number | number | d (mm) | D (mm) | T (mm) | Dynamic | Static | Grease | Oil | approximate |
| | | C0 | r/min | r/min | KG |
| 51200 | 8200 | 10 | 26 | 11 | 12.7 | 17.1 | 5700 | 8800 | 0.03 |
| 51201 | 8201 | 12 | 28 | 11 | 13.2 | 19 | 5400 | 8300 | 0.034 |
| 51202 | 8202 | 15 | 32 | 12 | 16.6 | 24.8 | 4900 | 7500 | 0.046 |
| 51203 | 8203 | 17 | 35 | 12 | 17.2 | 27.3 | 4900 | 7500 | 0.053 |
| 51220 | 8220 | 100 | 150 | 38 | 147 | 410 | 1200 | 1900 | 2.36 |
| 51222 | 8222 | 110 | 160 | 38 | 148 | 431 | 1200 | 1800 | 2.57 |
| 51224 | 8224 | 120 | 170 | 39 | 154 | 472 | 1100 | 1700 | 2.86 |
| 51226 | 8226 | 130 | 190 | 45 | 203 | 622 | 970 | 1500 | 4.09 |
| 51228 | 8228 | 140 | 200 | 46 | 215 | 669 | 940 | 1450 | 4.46 |
| 51230 | 8230 | 150 | 215 | 50 | 244 | 768 | 840 | 1300 | 5.64 |
FAQ:
1. What is your Before-sales Service?
1>.Offer to bear related consultation about technology and
application;
2>.Help customers about bearing choice, clearance configuration,
products' life, and reliability analysis;
3>.Offer a highly cost-effective and complete solution program
according to site conditions;
4>.Offer a localized program on introduced equipment to save
running cost
5>.Design and develop non-standard bearing to support customers'
technology innovation
2. What is your After-sales Service?
1>.Offer training about bearing installation and maintenance;
2>.Offer guidance about bearing installation, adjustment, and
testing at the site;
3>.Help customers with trouble diagnosis and failure analysis;
4>.Visit customers regularly and feedback their rational
suggestions and requirements to the company
Sales points:
1. Cheap price with good quality, good sales in the market.
2. We use good quality grease to make sure the bearing can turn
smooth and life can be longer.
3.OEM service, you can make your logo in bearing or send your
design sample to us, we can do the customization for you.
Contact us:
Dear friend, any questions please feel free to contact us, welcome
to inquiry!
