Best quality Long life Chrome steel Double Row Spherical Roller
Bearing 22218E/EK/E1/CW/CA/CC
Description:
| Subject | Symbol | Description |
| Radial internal clearance | C2 | Less than normal. |
| CN | Normal clearance. Is not indicated as a standard. |
| C3 | Greater clearance than normal. |
| C4 | Greater than C3. |
| C5 | Greater than C4. |
| Other technical modifications | W33 | All bearings are equipped with an annular groove and three
lubrication holes in the outer ring. |
| K | Tapered bore. |
| Cage types | C | Steel cage design bearings have two stamped window-type steel
cages, an inner ring without flanges and a floating guide ring
centered on the inner ring. |
| MB | Split brass cage, centered on the inner ring. There are hardboard
in the center and two boards in the outer sides. |
| M | Machined solid brass cage. |
| Tolerances | P0 | Normal tolerance level. Is not indicated as a standard. |
| P6 | Greater tolerance level than P0. |
| P5 | Greater tolerance level than P6. |
| Others | all other types are available,such
as:CW33,MW33,KCW33;KMW33;E;EK;E1,E1K;CCK/W33;CAK/W33;EKJA/VA;EJA/VA;EK+H |
|
|
Best quality Long life Chrome steel Double Row Spherical Roller
Bearing 22218E/EK/E1/CW/CA/CC
Spherical Bearing Features
1) The spherical roller bearing is principally provided with two
rows of symmetrical spherical rollers and a common sphered raceway
in the out ring.
2) With good self-aligning ability and can operate when the shaft
deflection under load or the shaft deflection under load or the
shaft misalignment in mounting, and their permissible aligning
angle is 1 to 2.5 degree
3) This type of bearings has heavy load carrying capacity and
anti-impact ability, in addition to radial loads, they also can
carry axial loads in two directions
4) In general, this type of bearings permits a low limiting speed.
The Drawing:
Relatives:
| Bearing No. | Size(mm) |
| New | Old | d | D | T | E |
|
| 29412 | 9039412 | 60 | 130 | 42 | 38 |
| 29413 | 9039413 | 65 | 140 | 45 | 42 |
| 29414 | 9039414 | 70 | 150 | 48 | 44 |
| 29415 | 9039415 | 75 | 160 | 51 | 47 |
| 29416 | 9039416 | 80 | 170 | 54 | 50 |
| 29317 | 9039317 | 85 | 150 | 39 | 50 |
| 29417 | 9039417 | | 180 | 58 | 54 |
| 29318 | 9039318 | 90 | 155 | 39 | 52 |
| 29418 | 9069418 | | 190 | 60 | 56 |
| 29320 | 9039320 | 100 | 170 | 42 | 58 |
| 29420 | 9039420 | | 210 | 67 | 62 |
| 29322 | 9039322 | 110 | 190 | 48 | 64 |
| 29422 | 9039422 | | 230 | 73 | 69 |
| 29324 | 9039324 | 120 | 210 | 54 | 70 |
| 29424 | 9039424 | | 250 | 78 | 74 |
| 29326 | 9039326 | 130 | 225 | 58 | 76 |
| 29426 | 9039426 | | 270 | 85 | 81 |
| 29328 | 9039328 | 140 | 240 | 60 | 82 |
| 29428 | 9039428 | | 280 | 85 | 86 |
Why Choose Us
1). World-Class Bearing: We provide our customer with different
kinds of Standard and Non-standard World-Class Bearing
2). Technical Testing: Company will check the products one by one
before sending you.
3). Technical Assistance: Company can provide you all related
technical data if you needed
4). Quick Delivery: You will get your goods within 7 working days
after your payment.
5). After-sale service: we support 24 Hours after-sale service
displacement on the radial clearance.
