Angular Contact Ball Bearing Description:
Angular contact ball bearing can withstand radial load and axial load simultaneously, as well as the pure axle loads. They have higher limit speed. High precision and high-speed bearings usually take 15 degrees to contact Angle. The contact angle decides the capacity of the axial load. Retainers are made of brass, synthetic resins or others subject to individual bearing features and application conditions.
Single-row angular contact ball bearings can accommodate axial load in one direction, if enduring radial load, it will raise additional axial force. And the only limited axial displacement of the shaft or housing in one direction. The contact angle of angular contact ball bearings is 40, so you can afford a large axial load. The design of angular contact ball bearing is non-separable, shoulder height on both sides of the inners and outer rings are different. In order to increase the bearing load capacity, lower one side of the shoulder, so that the bearing can be mounted into more balls.

Angular Contact Ball Bearing Application :
Machine tool spindle,
High-frequency motor,
Gas turbine,
Centrifuge,
Oil pump,
Roots blower,
Air compressor,
Transmission,
Printing machinery.
