High quality 2312 2312K 2313 Double Row Self-Aligning Radial Ball
bearing
Product description:
| Product name | 2312 self-aligning ball bearing |
| Brand | YGB, OEM |
| Basic dynamic load rating | 87.1 kN |
| Basic static load rating | 28.5 kN |
| Reference speed | 9500 r/min |
| Limiting speed | 7000 r/min |
| d(mm) | 60 |
| D(mm) | 130 |
| B(mm) | 46 |
| Cage | Nylon/Steel/Brass cage |
| Material | Chrome steel /stainless steel |
| Number of rows | Double row |
| Delivery time | <5000pcs,within 5 days after payment |
Product Description
In a self-aligning bearing, the inner ring has two raceways and the
outer ring has a single spherical raceway with its center of
curvature coincident with the bearing axis. Self-Aligning Double
Row Ball Bearings are designed to work in applications where severe
misalignment exists whether from mounting or shaft deflection. The
concave raceway of the outer ring in combination with two rows of
balls operate over a wide range of contact angles.
The drawing:
Spherical Roller Bearing Information:
(Universal Series 12xx, 13xx, 22xx, 23xx)
1. Roller bearings use rolling elements to maintain the separation
between moving parts to reduce rotational friction and support
radial and axial loads.
These elements can be one of the following types: ball,
cylindrical, spherical, barrel, needle, spindle, or tapered.
2. All roller bearings are open, shielded, or sealed.
3. Sealed bearings are lubricated with oil or grease in the bearing
factory, while open and shielded bearings are meant to be
lubricated in place, with periodic reapplication of lubrication,
based on use.
4. The shield protects the working parts of the bearing from
environmental debris that may be introduced and could reduce the
ball bearing speed and lifespan.
5. This structure of type is Cylindrical and tapered holes.
Advantage:
(1)High-Quality Steel-Ultra clean steel to extend bearing life by up
to 80%.
(2)Advanced Grease Technology
(3)High-Grade Balls - Quiet and smooth operation even at high speed.
(4)Super Finished Raceways - Specially honed to minimize noise and
improve lubricant distribution and life.
Application:
Suitable for precision instruments, low noise motors, automobiles,
motorcycles, and general machinery, etc. It is the most widely used
type of bearing in the machinery industry.
