Mechanical parts steel ball retainer 65*140*33 deep groove ball
bearing 6313 2rs
Product Description:
| Inside Diameter | 65mm |
| Outside Diameter | 140mm |
| Ball Bearing Type | Deep Groove |
| Race Width | 33mm |
| End Type | Open |
| Number of Rows | 1 |
| Static Load Rating | 60kN |
| Material | Steel |
| Cage Material | Steel |
| Race Type | Plain |
| Dynamic Load Rating | 97.5 kN |
| Limiting Speed | 5300rpm |
| Reference Speed | 10000rpm |
| Bore Type | Parallel |
Single row deep groove ball bearings are used in a wide variety of
applications, they are simple in design, non-separable, suitable
for high speeds and are robust in operation, and need little
maintenance. Deep raceway grooves and the close conformity between
the raceway grooves and the balls enable deep groove ball bearings
to accommodate axial loads in both directions, in addition to
radial loads.
Single row deep groove ball bearings are manufactured as open type
(unsealed), sealed and shielded, the most popular sizes of deep
groove ball bearings are also produced in sealed versions with
shields or contact seals on one or both sides, the bearings with
shields or seals on both sides are lubricated for life and are
maintenance-free. A sealed bearings seals have contact on the
bearings inner and outer, a shielded bearings shield has contact on
the outer only, and Shielded bearings are primarily intended for
applications where the inner ring rotates. If the outer ring
rotates, there is a risk that the grease will leak from the bearing
at high speeds.
The Drawing:
Quality Assurance
As per the regulation of three-dimensional management and multiple
checks, each product was inspected by the producer, inspector,
inspection development and quality development laboratory,
especially to the important inspection items and precision
inspection item. The quality of the products is the most important
as well as the lifeline for the enterprise. In order to process the
leading technology, we implement the quality control system and
establishes a technical and strict inspection team. The quality of
the products is the most important as well as the lifeline for the
enterprise. In order to process the leading technology, we
implement the quality control system and establishes a technical
and strict inspection team.
Our service
We will make customers have a feeling of satisfaction. We always
insist on our aim to supply customers with good quality products
with competitive prices and good service. We provide high quality,
excellent service and good credit for our company, as well as our
highest honor and we provide OEM and Customized service.
