Brand Name : | YGB,OEM,SKF,NTN |
Model Number : | 29324 Spherical Roller Bearing |
Certification : | ISO9001:2008 |
Price : | negotiation |
Payment Terms : | T/T or L/C |
Supply Ability : | 10000 pce per month |
Delivery Time : | 5-10 days after received your payment |
Self-aligning Thrust Roller Bearing 29324 E Machinery Bearing
Product Description
Product name | thrust ball bearing |
Series | 29324 E |
Material | bearing steel GCr15, stainless steel, chrome steel |
Cage | stainless steel, brass, nylon |
Precision | P0,P6,P5,P4,P2 |
clearance codes | C2, C3, C4, C5 |
Quality | ISO9001:2000 Standard |
Bore size | 35mm |
Outer diameter | 62mm |
Thickness | 18mm |
Seal type | Open |
Ball row number | Single row and double row |
Features | Suitable for high speed even extremely high speed; Durable, less maintenance frequency; Simple structure, low cost, Various sizes, and designs. |
Application | in precision instruments, low noise motor, automobile, and other machine industries. |
29324 E Thrust roller bearings are separable bearings, can only withstand axial load and a slight impact, to limit the shaft (or shell) of the axial displacement in one direction, it can be used as single-axis to the position. But its carrying capacity is far greater than the thrust ball bearings.
Thrust roller bearings are mainly used for heavy-duty machine
tools, power marine gearboxes, oil rig, electrical and other
machinery in the vertical.
The drawing
Cylindrical roller bearings are available in many designs, series, and sizes. The majority are single row bearings with a cage. High-capacity bearings, double row bearings, multi-row bearings, single, double and multi-row full complement bearings (without a cage) and split bearings complete the international standard assortment provided here.
Bearings with a cage can accommodate heavy radial loads, rapid accelerations and high speeds. Full complement bearings incorporate a maximum number of rollers and are therefore suitable for very heavy radial loads at moderate speeds. CHIK high-capacity cylindrical roller bearings combine the high load-carrying capacity of a full complement bearing with the high-speed capability of a bearing with a cage.
1. Cylindrical roller bearings feature high radial load because the
rollers and raceway are in linear contact
2. The NU and N types exhibit their best performance when used as
free side bearings since they adjust to the shaft axial movement,
to a certain extent, relative to the housing position
3. The NJ and NF types carry a certain degree of axial displacement
in both directions so they also use
das free side bearings
4. Models available: NU, NG, NUP, N, NF, NH, NNU, NIV
5. Moreover, we can manufacture these bearings according to
customer's drawings and samples.
Single row cylindrical roller bearings as for the ring ribs divided
into N-type, NU type, NJ and NUP type and so on. Cylindrical roller
bearings withstand heavily capacity of the radial load. But
according to the structure of ring ribs can also be under some
one-way or two-way axial load.NN and NNU type double row
cylindrical roller bearings are compact structure, which with
strong rigidity and bears load capacity. Even if it has to bear a
heavy load, its deformation is small. It mostly used for machine
tool spindle bearing.
FC, FCD, FDCP-type four-row cylindrical roller bearings can bear
greater radial load, mostly using for rolling mill and other heavy
machinery.
Relatives
Part No. | d | D | B | Part No. |
29412E | 60 | 130 | 42 | 29412 E |
29413E | 65 | 140 | 45 | 29413 E |
29414E | 70 | 150 | 48 | 29414 E |
29415E | 75 | 160 | 51 | 29415 E |
29416E | 80 | 170 | 54 | 29416 E |
29317E | 85 | 150 | 39 | 29317 E |
29417E | 85 | 180 | 58 | 29417 E |
29318E | 90 | 155 | 39 | 29318 E |
29418E | 90 | 190 | 60 | 29418 E |
29320E | 100 | 170 | 42 | 29320 E |
29420E | 100 | 210 | 67 | 29420 E |
29322E | 110 | 190 | 48 | 29322 E |
29422E | 110 | 230 | 73 | 29422 E |
29324E | 120 | 210 | 54 | 29324 E |
29424E | 120 | 250 | 78 | 29424 E |
29326E | 130 | 225 | 58 | 29326 E |
29426E | 130 | 270 | 85 | 29426 E |
29328E | 140 | 240 | 60 | 29328 E |
29428E | 140 | 280 | 85 | 29428 E |
29230E | 150 | 215 | 39 | 29230 E |
29330E | 150 | 250 | 60 | 29330 E |
29430E | 150 | 300 | 90 | 29430 E |
29332E | 160 | 270 | 67 | 29332 E |
29432E | 160 | 320 | 95 | 29432 E |
29334E | 170 | 280 | 67 | 29334 E |
29434E | 170 | 340 | 103 | 29434 E |
29236E | 180 | 250 | 42 | 29236 E |
29336E | 180 | 300 | 73 | 29336 E |
29436E | 180 | 360 | 109 | 29436 E |
Our service
We provide OEM service and Customized Service
We always insist on our aim to supply customers with good quality products with competitive prices and good service.
![]() |
