Brand Name : | YGB,OEM,SKF,NTN |
Model Number : | NJ314ECM |
Certification : | ISO9001:2008 |
Price : | negotiation |
Payment Terms : | T/T or LC |
Supply Ability : | 10,000pcs per month |
Delivery Time : | 5-10 working days after received your payment |
Double Shields Full Complement Cylindrical Roller Bearing NJ314ECM
C3 70 x 150 x 35 MM
Description :
Model | NJ314ECM |
Bearing material | GCr15/AISI52100/100Cr6 |
ID*OD*W (mm) | 70 x 150 x 35 mm |
Seal type | double shields |
Lead time | Stock or 15-30days |
Weight(kg) | 3.23 |
Limiting speed | 5600 r/min |
Clearance | C2,C0,C3,C4,C5 |
Viberation Level | V1,V2,V3,V4 |
Precision Rating | P0,P6,P5, |
MOQ | No MOQ |
Port | Shanghai |
Grease | Mobil polyrex EM,Kyodo Yushi SRL |
Payment terms | T/T, L/C |
Principal dimension(mm) | Weight(kg) | Bearing number | Basic Load Rating(KN) | Speed(rpm) | ||||||
d | D | B | R1min | Rsmin | Dynamic Cr | Static Cor | reference | Limited | ||
15 | 35 | 11 | 0.6 | 0.3 | 0.050 | N202 | 12.7 | 10.4 | 20000 | 22000 |
15 | 35 | 11 | 0.6 | 0.3 | 0.050 | NJ202 | 12.7 | 10.4 | 20000 | 22000 |
15 | 35 | 11 | 0.6 | 0.3 | 0.050 | NU202 | 12.7 | 10.4 | 20000 | 22000 |
17 | 40 | 12 | 0.6 | 0.3 | 0.06 | N203 | 17.6 | 14.6 | 10000 | 18000 |
17 | 40 | 12 | 0.6 | 0.3 | 0.06 | NJ203 | 14.5 | 12.8 | 18000 | 18000 |
20 | 47 | 14 | 1.0 | 0.6 | 0.109 | N204 | 16.6 | 13.9 | 17000 | 20000 |
20 | 47 | 14 | 1.0 | 0.6 | 0.111 | NJ204 | 16.6 | 13.9 | 17000 | 20000 |
20 | 47 | 14 | 1.0 | 0.6 | 0.111 | NU204EM | 16.6 | 13.9 | 17000 | 20000 |
20 | 52 | 15 | 1.1 | 0.6 | 0.149 | N304 | 23.1 | 19.2 | 14000 | 17000 |
20 | 52 | 15 | 1.1 | 0.6 | 0.153 | NJ304 | 23.1 | 19.2 | 14000 | 17000 |
20 | 52 | 15 | 1.1 | 0.6 | 0.153 | NU304 | 23.1 | 19.2 | 14000 | 17000 |
25 | 52 | 15 | 1.0 | 0.6 | 0.160 | N205EM | 27.5 | 26.8 | 11000 | 14000 |
25 | 52 | 15 | 1.0 | 0.6 | 0.137 | NJ205 | 18.8 | 17 | 14000 | 17000 |
25 | 52 | 18 | 1.1 | 0.6 | 0.170 | NJ2205V | 35.3 | 29.4 | 12000 | 25000 |
25 | 52 | 15 | 1.0 | 0.6 | 0.160 | NU205EM | 27.5 | 26.8 | 11000 | 14000 |
25 | 62 | 17 | 1.1 | 1.1 | 0.235 | N305 | 31.5 | 27.7 | 12000 | 14000 |
25 | 62 | 17 | 1.1 | 1.1 | 0.241 | NJ305 | 31.5 | 27.7 | 12000 | 14000 |
25 | 62 | 17 | 1.1 | 1.1 | 0.241 | NU305 | 31.5 | 27.7 | 12000 | 14000 |
25 | 62 | 24 | 1.1 | 1.1 | 0.370 | NJ2305V | 67 | 72.7 | 7200 | 10000 |
Drawing:
Shipping:
1). For small orders, we can send you by UPS, DHL, FEDEX. The
tracking number will be advised after delivery.
2). If an order is big, we will advise you to use Air Freight or
Sea Freight.
3). The balance payment should be paid before delivery to you.
4). In general, we deliver goods within 15 days.
Payment
1: T/T: 30% as deposit and 70% balance after getting a copy of B/L.
2: L/C (cannot for branded bearings.)
3: Discuss together between buyer and supplier.
Dear friend, any questions please feel free to contact us, let's
learn and grow together in bearing worlds!
![]() |
