Large quantity cylindrical roller bearing 2314 km N314 ECJ F3 fast
delivery
Product description:
Suffix:
CA: Integral brass cage, double row symmetrical roller, inner ring
ride
CC: Two window-type steel cages, double row symmetrical roller,
inner ring ride
MA: Machined brass cage, outer ring ride
MB: Machined brass cage, inner ring ride
K: Tapered bore, taper 1:12
K30: Tapered bore, taper 1:30
S: With a groove, lubrication holes in out rings.
W: Without annular groove and lubrication holes in outer ring
W20: Three lubrication holes in outer ring
W26: Six lubrication holes in inner ring
W33: Annular groove and three lubrication holes in outer ring
W77: Plugged W33 lubrication holes
| Model number | NJ 2314 |
| Dimension(mm) | 70*150*51 |
| Weigh(kg) | 4.1 |
| Greese/Oil | As you requirement,such as SRL ,PS2,AIVania R12 and so on |
| Series | Cylindrical Roller Bearing |
| Ring Material | Chrome Steel,Carbon steel,bearing steel |
| Quality standard | ISO 9001:2000 standard |
| Precision | p0,p6,p5,p4 |
| Steel pressed cage | Bending claw form or rivet form |
| Delivery Date | Normally ready goods and stock within 7 days |
| Payment Term | T/T, L/C,Western Union |
| Application | Home appliances,low noise and high speed electric motors,automotive
components,pumps |
| Service | OEM ODM |
| Package | industrial package+paper box/wooden box single package+paper
box/wooden box |
| Details | We have complete process for the production and quality assurance
to make sure our product |
| 1.Assembly 2,Windage test 3,Cleaning 4,Rotary test 5,Greasing and
gland 6,Noise inspection |
| 7,Rust prevention 9,Product packaging |
Types of cylindrical roller bearing:
Single row cylindrical roller bearing: NU, NJ, NUP, NUB series
Double row cylindrical roller bearings:NNU series
Four row cylindrical roller bearing:FC series
Single row full complement cylindrical roller bearing:SL18 series,
SL 19 series
Double row full complement cylindrical roller bearing: SL01 series,
SL02 series, SL18 series.
Single row cylindrical roller bearing size
| New items | Code(dxDxB) | Weight/kg | New items | Code(dxDxB) | Weight/kg |
| NU202 E | 15*35*11 | 0.07 | NU202EM | 15*35*11 | 0.07 |
| NU203 E | 17*40*12 | 0.075 | NU203EM | 17*40*12 | 0.075 |
| NU204E | 20*47*14 | 0.11 | NU204EM | 20*47*14 | 0.11 |
| NU205 E | 25*52*15 | 0.137 | NU205EM | 25*52*15 | 0.137 |
| NU206 E | 30*62*16 | 0.211 | NU206EM | 30*62*16 | 0.211 |
| NU207 E | 35*72*17 | 0.3 | NU207EM | 35*72*17 | 0.3 |
| NU208 E | 40*80*18 | 0.382 | NU208EM | 40*80*18 | 0.382 |
| NU209 E | 45*85*19 | 0.483 | NU209EM | 45*85*19 | 0.438 |
| NU210 E | 50*90*20 | 0.493 | NU210EM | 50*90*20 | 0.493 |
| NU211 E | 55*100*21 | 0.65 | NU211EM | 55*100*21 | 0.65 |
| NU212 E | 60*110*22 | 0.84 | NU211EM | 60*110*22 | 0.84 |
| NU213 E | 65*120*23 | 1.07 | NU213EM | 65*120*23 | 1.07 |
The drawing:
Spherical Roller Bearing Information:
(Universal Series 12xx, 13xx, 22xx, 23xx)
1. Roller bearings use rolling elements to maintain the separation
between moving parts to reduce rotational friction and support
radial and axial loads.
These elements can be one of the following types: ball,
cylindrical, spherical, barrel, needle, spindle, or tapered.
2. All roller bearings are open, shielded, or sealed.
3. Sealed bearings are lubricated with oil or grease in the bearing
factory, while open and shielded bearings are meant to be
lubricated in place, with periodic reapplication of lubrication,
based on use.
4. The shield protects the working parts of the bearing from
environmental debris that may be introduced and could reduce the
ball bearing speed and lifespan.
5. This structure of type is Cylindrical and tapered holes.
Advantage:
(1)High-Quality Steel-Ultra clean steel to extend bearing life by up
to 80%.
(2)Advanced Grease Technology
(3)High-Grade Balls - Quiet and smooth operation even at high speed.
(4)Super Finished Raceways - Specially honed to minimize noise and
improve lubricant distribution and life.
Application:
Suitable for precision instruments, low noise motors, automobiles,
motorcycles, and general machinery, etc. It is the most widely used
type of bearing in the machinery industry.
